Small Animal SPECT Imaging

Principal Investigator: Scott D. Metzler

Background

Small animals are used in numerous capacities in biomedical research. By utilizing imaging at various time points for the same small animal, non-invasive data can be collected. This improves the science by allowing each animal to serve as its own control over time and it reduces the number of animals needed in research. In addition, significant advances in gene-editing techniques allow for studying diseases at the genetic and molecular level. This is not practical in any other way.

SPECT Projects

We have been developing a specialized collimator for cardiac mouse imaging that allows for focusing numerous pinholes at the mouse heart. The pinholes magnify the heart and allow for reconstruction in 3D without any motion of the mouse or the scanner. This project utilized 3D printing techniques to manufacture unique rectangular apertures to minimize overlap on the detectors.

We have been developing techniques to measure the flow of blood to the mouse heart. This is analogous to human imaging with PET. However, at the human scale PET imaging typically has better resolution than SPECT imaging due to differences in the acquisition process. However, SPECT imaging can magnify the region of interest when the object is small. Thus, SPECT imaging of mice with pinholes typically has better resolution than PET. Despite this, quantifying the flow of blood to the mouse’s heart is technically very challenging.

Sample Images

We are able to image the mouse heart with very high resolution and use regions of interest to extract quantitative data.

A detailed description can be found following this image.
Top: Different planes through the 3D reconstruction of a mouse heart. Bottom: Regions of interest include the myocardium (yellow) and the blood pool (green).



Related Publications

  1. S. D. Metzler and S.C. Moore, "Analytic Determination of Rectangular-Pinhole Sensitivity With Penetration’’, IEEE Transactions on Medical Imaging, 2019 (in press). [Analytic Determination of Rectangular-Pinhole Sensitivity With Penetration]
  2. L.C. Johnson, M.A. Guerraty, S.C. Moore, and S.D. Metzler, “Quantification of myocardial uptake rate constants in dynamic small-animal SPECT using a cardiac phantom,” Physics in Medicine and Biology, 2019. [Quantification of myocardial uptake rate constants in dynamic small-animal SPECT using a cardiac phantom]
  3. S.C. Moore, M.-A. Park, Z. Liu, M.C. Lyon, L.C. Johnson, V.H. Lushear, J.G. Westberg, and S.D. Metzler, “Design of a dual-resolution collimator for preclinical cardiac SPECT with a stationary triple-detector system,” Medical Physics, 2016. [Design of a dual-resolution collimator for preclinical cardiac SPECT with a stationary triple-detector system]
  4. M.C. Lyon, A. Sitek, S.D. Metzler, and S.C. Moore, “Reconstruction of multiple-pinhole micro-SPECT data using origin ensembles,” Medical Physics, 2016. [Reconstruction of multiple-pinhole micro-SPECT data using origin ensembles]
  5. L.C. Johnson, S.C. Moore, and S.D. Metzler, “Effect of pinhole shape on projection resolution,” Physics in Medicine and Biology, 2016. [Effect of pinhole shape on projection resolution]
  6. D. Xia, S.C. Moore, M.-A. Park, M. Cervo, and S.D. Metzler, “Investigation of imaging properties for submillimeter rectangular pinholes,” Medical Physics, 2015. [Investigation of imaging properties for submillimeter rectangular pinholes]
  7. K. Van Audenhaege, R. Van Holen, S. Vandenberghe, C. Vanhove, S.D. Metzler, and S.C. Moore, “Review of SPECT collimator selection, optimization, and fabrication for clinical and preclinical imaging,” Medical Physics, 2015. [Review of SPECT collimator selection, optimization, and fabrication for clinical and preclinical imaging]
